729,80 PLN
Plummer block housing units RASEL, cast iron housing, non-locating bearing, drive slot on inner ring, R seals
| Class description short | Plummer block housing unit |
| Mass netto | 4.42 kg |
| Operating temperature min. | -40.0 °C |
| Operating temperature max. | 180.0 °C |
| REACH | REACH compliant with declarable lead proportion |
| RoHS | RoHS compliant with declarable substances |
| Bearing designation | GLE60-XL-KRR-B |
| Bore diameter | 60.0 mm |
| Brand | INA |
| Connection thread for lubrication | M6 |
| Distance of raceway to locking collar | 37.3 mm |
| Distance fixing bore | 190.0 mm |
| Distance shaft axis | 69.9 mm |
| Bearing in kit | GLE60-XL-KRR-B |
| Bearing sealed | Yes |
| Bearing sort | RIBB |
| Bearing split | No |
| Housing opening | combi |
| Distance between mounting bolt centerlines (length) | 190.0 mm |
| Height bearing seat | 69.9 mm |
| Housing height | 140.0 mm |
| Housing in kit | RASEL60-XL-N |
| Housing material | GG |
| Housing shape | Fuss_lang |
| Housing sort | Plummer |
| Housing split | Nein |
| Inner diameter bearing | 60.0 mm |
| Housing length | 240.0 mm |
| Location on shaft | Acc |
| Housing qty bolts | 2 |
| Outer diameter bearing | 110.0 mm |
| Sealing type | LIP |
| Housing width | 61.9 mm |
| Basic dynamic load rating | 56000.0 N |
| Basic static load rating | 36000.0 N |
| Height | 140.0 mm |
| Height (base) | 25.0 mm |
| Housing | ASE12-FA125 |
| Length (slot) | 28.0 mm |
| Length total | 240.0 mm |
| Marketing category | XL |
| Material | GG |
| PFAS | ja |
| Protecting cap | KASK12 |
| Width (base) | 60.0 mm |
| Width (head) | 42.0 mm |
| Width | 61.9 mm |
| Width (slot) | 18.0 mm |
| Groove | N |
