3151,20 zł
Miniature Guideway; for Miniature-Carriage, Standard and Long design
| Class description short | Miniature Guideway for Miniature-Carriage, Standard design |
| Mass netto | 1.47 kg |
| REACH | REACH compliant for SVHC free linear products (acc to PL responsibles) |
| Accuracy class | G2 |
| Brand | INA |
| Distance between start of guideway and nearest hole | 20.0 mm |
| Distance between end of guideway and nearest hole | 20.0 mm |
| Distance between start of guideway and nearest hole | 5.0 mm |
| Distance between end of guideway and nearest hole | 5.0 mm |
| ~Guideway length | ~2000 |
| Height | 8.8 mm |
| Increment | 25.0 mm |
| Length | 4.3 mm |
| Material name | TKDM |
| Max length single piece guideway | 2000.0 mm |
| Size code | 12 |
| Thread | M3 |
| Tightening torque | 1.1 Nm |
| Version | E |
| Width rail | 12.0 mm |
