2924,80 zł
Miniature Guideway, Wide design; for Miniature- Carriage, Wide and Wide-Long design
| Class description short | Miniature Guideway for Miniature-Carriage, Standard design |
| Mass netto | 1.06 kg |
| REACH | REACH compliant for SVHC free linear products (acc to PL responsibles) |
| Accuracy class | G2 |
| Brand | INA |
| Distance between start of guideway and nearest hole | 25.0 mm |
| Distance between end of guideway and nearest hole | 25.0 mm |
| Distance between start of guideway and nearest hole | 5.0 mm |
| Distance between end of guideway and nearest hole | 5.0 mm |
| Guideway design | W |
| ~Guideway length | ~2000 |
| Height | 5.2 mm |
| Increment | 30.0 mm |
| Length | 1.7 mm |
| Max length single piece guideway | 2000.0 mm |
| Size code | 07 |
| Thread | M3 |
| Tightening torque | 1.1 Nm |
| Version | E |
| Width rail | 14.0 mm |
