469,40 zł
brutto · 381,63 zł netto
Kupujesz na firmę? Ceny netto i progi ilościowe w Strefie Partnera.
| Średnica wewnętrzna d | 40mm |
|---|---|
| Średnica zewnętrzna D | 68mm |
| Szerokość B | 38mm |
| Obciążenie dynamiczne C | 80 000N |
| Obciążenie statyczne C₀ | 111 000N |
| Masa | 0,516kg |
| Klasa luzu | CN (Group N) |
| Temperatura pracy | -30…120°C |
| Chamfer angle |
|---|
| 30° |
| Chamfer width | 0,8mm |
|---|
| Diameter of groove | 65,8mm |
|---|
| Distance between rolling elements | 28,5mm |
|---|
| Distance ring grooves | 32,2mm |
|---|
| Fatigue load limit, radial | 16 300N |
|---|
| Limiting speed for grease lubrication | 3 1501/min |
|---|
| Lower distance retaining ring tolerance | -0,2mm |
|---|
| Lower distance ring groove tolerance | 0mm |
|---|
| Lower distance snap ring tolerance | -0,2mm |
|---|
| Minimum diameter shaft shoulder | 51,5mm |
|---|
| Minimum chamfer dimension | 0,6mm |
|---|
| Mounting dim for snap ring WRE (not included in delivery) Tolerance: 0/-0,2 | 28mm |
|---|
| Mounting dim for retaining ring to DIN 471 (not incl. In delivery) Tol: 0/-0,2 | 27mm |
|---|
| Number of rows | 2 |
|---|
| Outside diameter of snap ring WRE | 75mm |
|---|
| Rib diameter inner ring | 51,5mm |
|---|
| Sealing diameter (rib) | 55mm |
|---|
| Tolerance class | PN |
|---|
| Upper distance retaining ring tolerance | 0mm |
|---|
| Upper distance ring groove tolerance | 0,2mm |
|---|
| Upper distance snap ring tolerance | 0mm |
|---|
| Width of groove | 2,7mm |
|---|
| Width, outer ring | 37mm |
|---|
