411,90 zł
brutto · 334,88 zł netto
Kupujesz na firmę? Ceny netto i progi ilościowe w Strefie Partnera.
| Średnica wewnętrzna d | 30mm |
|---|---|
| Średnica zewnętrzna D | 55mm |
| Szerokość B | 34mm |
| Obciążenie dynamiczne C | 50 000N |
| Obciążenie statyczne C₀ | 67 000N |
| Masa | 354g |
| Klasa luzu | CN (Group N) |
| Temperatura pracy | -20…80°C |
| Chamfer angle |
|---|
| 30° |
| Chamfer width | 0,5mm |
|---|
| Diameter of groove | 53mm |
|---|
| Distance between rolling elements | 25,5mm |
|---|
| Distance ring grooves | 28,2mm |
|---|
| Fatigue load limit, radial | 9 700N |
|---|
| Limiting speed for grease lubrication | 4 1001/min |
|---|
| Lower distance retaining ring tolerance | -0,2mm |
|---|
| Lower distance ring groove tolerance | 0mm |
|---|
| Lower distance snap ring tolerance | -0,2mm |
|---|
| Minimum diameter shaft shoulder | 41mm |
|---|
| Minimum chamfer dimension | 0,3mm |
|---|
| Mounting dim for snap ring WRE (not included in delivery) Tolerance: 0/-0,2 | 25mm |
|---|
| Mounting dim for retaining ring to DIN 471 (not incl. In delivery) Tol: 0/-0,2 | 24mm |
|---|
| Number of rows | 2 |
|---|
| Outside diameter of snap ring WRE | 60mm |
|---|
| Rib diameter inner ring | 41mm |
|---|
| Sealing diameter (rib) | 44mm |
|---|
| Tolerance class | PN |
|---|
| Upper distance retaining ring tolerance | 0mm |
|---|
| Upper distance ring groove tolerance | 0,2mm |
|---|
| Upper distance snap ring tolerance | 0mm |
|---|
| Width of groove | 2,1mm |
|---|
| Width, outer ring | 33mm |
|---|
| Holding rings | 2NR |
|---|
| Sealing | PP |
|---|
