14 133,10 zł
brutto · 11 490,33 zł netto
Kupujesz na firmę? Ceny netto i progi ilościowe w Strefie Partnera.
| Średnica wewnętrzna d | 260mm |
|---|---|
| Średnica zewnętrzna D | 360mm |
| Szerokość B | 100mm |
| Obciążenie dynamiczne C | 1 100 000N |
| Obciążenie statyczne C₀ | 2 470 000N |
| Prędkość graniczna | 1 0101/min |
| Masa | 31,2kg |
| Klasa luzu | CN (Group N) |
| Temperatura pracy | -30…120°C |
| Reference speed | 5701/min |
|---|---|
| Axial displacement | 6mm |
| Bearing designation DIN5412 | NNCL4952V |
| Distance to lubrication hole | 50mm |
| Fatigue load limit, radial | 285 000N |
| Maximum rib diameter inner ring | 294,5mm |
| Maximum recess radius | 2,1mm |
| Minimum diameter of housing shoulder | 331mm |
| Minimum diameter shaft shoulder | 294,5mm |
| Minimum chamfer dimension | 2,1mm |
| Minimum shaft shoulder | 294,5mm |
| Number of rows | 2 |
| Raceway diameter outer ring | 331,33mm |
| Tolerance class | PN |
| Design | A |
