235,20 zł
Plummer block housing units RASEL, cast iron housing, non-locating bearing, drive slot on inner ring, R seals
| Class description short | Plummer block housing unit |
| Mass netto | 1.11 kg |
| Operating temperature min. | -40.0 °C |
| Operating temperature max. | 180.0 °C |
| REACH | REACH compliant with declarable lead proportion |
| RoHS | RoHS compliant with declarable substances |
| Bearing designation | GLE30-XL-KRR-B |
| Bore diameter | 30.0 mm |
| Brand | INA |
| Connection thread for lubrication | M6 |
| Distance of raceway to locking collar | 22.0 mm |
| Distance fixing bore | 117.5 mm |
| Distance shaft axis | 42.9 mm |
| Bearing in kit | GLE30-XL-KRR-B |
| Bearing sealed | Yes |
| Bearing sort | RIBB |
| Bearing split | No |
| Housing opening | combi |
| Distance between mounting bolt centerlines (length) | 117.5 mm |
| Height bearing seat | 42.9 mm |
| Housing height | 82.0 mm |
| Housing in kit | RASEL30-XL-N |
| Housing material | GG |
| Housing shape | Fuss_lang |
| Housing sort | Plummer |
| Housing split | Nein |
| Inner diameter bearing | 30.0 mm |
| Housing length | 158.0 mm |
| Location on shaft | Acc |
| Housing qty bolts | 2 |
| Outer diameter bearing | 62.0 mm |
| Sealing type | LIP |
| Housing width | 36.5 mm |
| Basic dynamic load rating | 20700.0 N |
| Basic static load rating | 11300.0 N |
| Height | 82.0 mm |
| Height (base) | 17.0 mm |
| Housing | ASE06 |
| Length (slot) | 22.0 mm |
| Length total | 158.0 mm |
| Marketing category | XL |
| Material | GG |
| PFAS | ja |
| Protecting cap | KASK06 |
| Width (base) | 40.0 mm |
| Width (head) | 25.0 mm |
| Width | 36.5 mm |
| Width (slot) | 14.0 mm |
| Groove | N |
