25 513,90 zł
brutto · 20 743,01 zł netto
Kupujesz na firmę? Ceny netto i progi ilościowe w Strefie Partnera.
| Średnica wewnętrzna d | 260mm |
|---|---|
| Średnica zewnętrzna D | 480mm |
| Szerokość B | 80mm |
| Obciążenie dynamiczne C | 1 350 000N |
| Obciążenie statyczne C₀ | 1 890 000N |
| Prędkość graniczna | 2 1001/min |
| Masa | 69,5kg |
| Klasa luzu | CN (Group N) |
| Koszyk | M1A |
| Temperatura pracy |
| -30…150°C |
| Reference speed | 1 1101/min |
|---|---|
| Axial displacement | 6,2mm |
| Fatigue load limit, radial | 142 000N |
| Maximum diameter of housing shoulder | 460mm |
| Maximum diameter of shaft shoulder | 314mm |
| Maximum recess radius | 4mm |
| Maximum recess radius | 4mm |
| Minimum diameter shaft shoulder | 280mm |
| Minimum rib diameter outer ring | 406,6mm |
| Minimum chamfer dimension | 5mm |
| Minimum chamfer dimension | 5mm |
| Minimum shaft shoulder | 320mm |
| Number of rows | 1 |
| Raceway diameter inner ring | 317mm |
| Raceway diameter outer ring | 429mm |
| Tolerance class | PN |
| Design | E |
