190,30 zł
brutto · 154,72 zł netto
Kupujesz na firmę? Ceny netto i progi ilościowe w Strefie Partnera.
| Średnica zewnętrzna D | 30mm |
|---|---|
| Obciążenie dynamiczne C | 6 800N |
| Obciążenie statyczne C₀ | 8 700N |
| Masa | 0,087kg |
| Width of the roller stud | 40mm |
|---|---|
| Bolt/stud length effectively | 25mm |
| Diameter lubrication hole | 3mm |
| Distance to lubrication hole |
| Drive-fit lubrication nipple | NIPA1X4,5 |
|---|
| Fatigue load limit, radial | 1 240N |
|---|
| Fit diameter of roller stud / stud | 12mm |
|---|
| Maximum witdh of thrust washer | 15,2mm |
|---|
| Minimum chamfer dimension | 0,6mm |
|---|
| Protrusion outer ring to thrust washer | 0,6mm |
|---|
| Radius of outer ring outside profile | 500mm |
|---|
| Speed on permanent grease lubrication | 5 5001/min |
|---|
| Stop diameter of thrust washer | 23mm |
|---|
| Thread | M12X1,5 |
|---|
| Thread length | 13mm |
|---|
| Tightening torque nut | 22Nm |
|---|
| Width of flats | 6mm |
|---|
| Width, outer ring | 14mm |
|---|
| Drive-fit lubrication nipple unmounted | 2x |
|---|
| Assembling aid stud | I6 |
|---|
| Assembling aid head | I6 |
|---|
| Outer ring profile | R500 |
|---|
| Relubrication | KSP |
|---|
| Sealing | SPSP |
|---|
