231,70 zł
Linear ball bearing and housing unit; sealed, greased, with relubrication facility; corrosion-resistant design possible
| Class description short | Linear Ball Bearing and Housing Unit |
| Mass netto | 30.0 g |
| Width | 32.0 mm |
| REACH | REACH compliant for SVHC free linear products (acc to PL responsibles) |
| RoHS | RoHS compliant |
| Brand | INA |
| Diameter of ball complement | 6.0 mm |
| Height | 27.0 mm |
| Center height | 13.0 mm |
| Length | 22.2 mm |
| Dynamic load rating | 340.0 N |
| Basic static load capacity | 240.0 N |
| Lower tolerance | 0.014 mm |
| Lower tolerance | 0.15 mm |
| Lubrication nipple | NIPA1 |
| Mounting Dimension | 20.6 mm |
| Mounting Dimension | 13.0 mm |
| PFAS | nein |
| Upper tolerance | 0.01 mm |
| Upper tolerance | 0.15 mm |
| Relubrication facility | AS |
| Seal | PP |
| Size code | 06 |
| Version | B |
