560,70 zł
brutto · 455,85 zł netto
Kupujesz na firmę? Ceny netto i progi ilościowe w Strefie Partnera.
| Średnica wewnętrzna d | 17mm |
|---|---|
| Średnica zewnętrzna D | 30mm |
| Szerokość B | 7mm |
| Obciążenie dynamiczne C | 2 480N |
| Obciążenie statyczne C₀ | 1 070N |
| Prędkość graniczna | 95 0001/min |
| Masa | 22g |
| Koszyk | T |
| Temperatura pracy | -30…80°C |
| Diameter shaft shoulder clearance | h12 |
|---|---|
| Tolerance class | P4S |
| Sealing | 2RSD |
| Distance between the apexes of the pressure cones | 9mm |
| Arrangement bearing set | U |
| Fatigue load limit, radial | 114N |
| Maximum recess radius | 0,3mm |
| Minimum chamfer dimension | 0,3mm |
| Minimum chamfer dimension | 0,3mm |
| Maximum recess radius | 0,1mm |
| Preload force light | 16N |
| Lift-off force light | 45N |
| Contact angle | 25° |
| Limiting speed for grease lubrication | 63 0001/min |
| Shoulder diameter outer ring | 27,5mm |
| Diameter shaft shoulder | 20mm |
| Contact angle | E |
| Lubricant | GA21 |
| Preload | L |
| Preload force medium | 47N |
| Preload force heavy | 93N |
| Lift-off force medium | 138N |
| Lift-off force heavy | 283N |
| Axial rigidity medium | 44N/µm |
| Axial rigidity heavy | 58N/µm |
| Axial rigidity light | 30N/µm |
| Shoulder diameter outer ring clearance | H12 |
