783,10 zł
brutto · 636,67 zł netto
Kupujesz na firmę? Ceny netto i progi ilościowe w Strefie Partnera.
| Obciążenie dynamiczne C | 419 000N |
|---|---|
| Obciążenie statyczne C₀ | 2 100 000N |
| Masa | 2,3kg |
| Klasa luzu | CN (Group N) |
| Temperatura pracy | -60…200°C |
| Ball diameter | 100mm |
|---|---|
| Bore diameter bearing, lower tolerance | -0,015mm |
| Bore diameter bearing, tolerance | 0,015 |
| Bore diameter bearing, upper tolerance |
|---|
| 0mm |
| Bore diameter bearing | 69,85mm |
|---|
| Coating | Durotect M |
|---|
| Connection measure Inner ring | 79,2mm |
|---|
| Edge Spacing | 1mm |
|---|
| Edge Spacing | 1mm |
|---|
| Housing Connection Diameter | 89mm |
|---|
| Maintenance | Maintenance required |
|---|
| Outside diameter, lower tolerance | -0,015mm |
|---|
| Outside diameter, upper tolerance | 0mm |
|---|
| Outside diameter bearing | 111,125mm |
|---|
| Radial Clearance | 0,1 -0,2 |
|---|
| Radial clearance, maximum | 0,2mm |
|---|
| Radial clearance, minimum | 0,1mm |
|---|
| Tilt angle | 6° |
|---|
| Width inner ring | 61,112mm |
|---|
| Width inner ring, lower tolerance | -0,15mm |
|---|
| Width inner ring, upper tolerance | 0mm |
|---|
| Width Outer ring | 52,375mm |
|---|
| Width outer ring, lower tolerance | -0,4mm |
|---|
| Width outer ring, upper tolerance | 0mm |
|---|
| Material | Steel |
|---|
| Sealing | Without |
|---|
